The Cheap Small Portable Car Vin Number Vin Code Chassis Number Marking Portable Marking Machine For Steel is a handy tool that allows you to easily mark various materials. With a weight of 8 kg and an electromagnetic stand, it is a pneumatic marking machine that works by the vibration caused by compressed air. It is suitable for marking on aluminum, stainless steel, wild steel, carbon steel, copper, iron, and other metal materials.
Features
- Support system: WindowsXP or Win7 system
- Marking range: 100x20mm
- Marking depth: 0.01-0.6mm (depending on the material)
- Engraving speed: about 1 second per character
- Marking direction: optional upper
- Voltage: 220V
- Frequency: 50HZ
- Power: about 200W
- Colour: Blue
- Gross weight: 14KG
Usage
The machine is widely used for marking on big metal parts such as car parts. It provides flexibility in setting the marking space and radian. The KT-PB series Handheld marking machine is perfect for marking car parts, VIN codes, plates, chassis numbers, and more. It requires a PC and a pump, but you also have the option of choosing the CNC box, which eliminates the need for a PC.
- Marking speed: 30mm – 40mm/s
- Impact Frequency: 300 times/s
- Repeated Accuracy: 0.001mm
- Marking Depth: 0.1mm – 2mm (depends on different materials)
- Power supply: AC220V 50HZ / AC110V 60HZ
- Air power request: 0.2 Mpa – 0.6 Mpa
- Humidity: 0-90% (Non-condensing)
- Temperature: 0 ~ 40 ℃
- Marking Content: English characters, numbers, all kinds of graphics, logos, dot matrix 2D codes, Barcodes, Serial Numbers, Circle letters, etc.
- Software Compatible: Windows 98/XP/7 32bit (series need to connect to PC) series integrate software, keyboard, and screen, no need to connect to PC.
Frequently Asked Questions
-
What materials can the marking machine work on?
- The marking machine is suitable for aluminum, stainless steel, wild steel, carbon steel, copper, iron, and other metal materials.
-
What is the weight of the marking head?
- The weight of the marking head is about 8 kg with an electromagnetic stand.
-
Do I need a PC to operate the marking machine?
- Yes, a PC is required to operate the marking machine. However, you have the option to choose the CNC box, which eliminates the need for a PC.
