The FT232BL FT232RL Basic Breakout Board is an indispensable tool that seamlessly bridges the gap between USB and TTL levels, unlocking a myriad of possibilities for electronic enthusiasts, hobbyists, and professionals alike. This remarkable device offers unparalleled versatility, enabling efficient debugging, downloading, and communication with various electronic systems, including the ever-popular Arduino platform.
Specifications and Features:
- Chipset: FTDI FT232RL, renowned for its exceptional reliability and performance.
- Voltage Levels: Supports both 3.3V and 5V levels, accommodating a wide range of applications.
- USB Interface: Convenient USB 2.0 Type-A connector provides seamless connectivity to your computer.
- TTL Signals: Includes transmit (TX), receive (RX), and ground (GND) pins for efficient data transfer.
- LED Indicators: Integrated LEDs provide visual feedback for power and data transmission status.
- Robust Construction: Durable PCB construction ensures long-term reliability even in demanding environments.
- Compact Design: Its small form factor makes it ideal for space-constrained projects.
Applications:
The FT232BL FT232RL Basic Breakout Board finds its utility in a diverse array of applications, including:
- Debugging: Establish a reliable communication channel with microcontroller-based systems for debugging and troubleshooting.
- Downloading: Program and update firmware on embedded systems with ease through its USB interface.
- Serial Communication: Facilitate communication between electronic devices via its TTL signals.
- Arduino Connectivity: Connect your Arduino board to a computer for programming, debugging, and data exchange.
Benefits:
- Effortless USB-to-TTL Conversion: Simplifies the conversion process, eliminating the need for complex circuitry.
- Enhanced Debug and Download Capabilities: Enables efficient debugging and firmware updates, saving time and effort.
- Broad Compatibility: Compatible with a wide range of electronic systems, including microcontrollers, sensors, and peripherals.
- Exceptional Value: Its low price point makes it an affordable solution for both personal and professional projects.
Frequently Asked Questions:
Q: What is the maximum data transfer rate supported by this board?
A: The FT232BL FT232RL Basic Breakout Board supports data transfer rates of up to 3 Mbps.
Q: Can this board be used with other microcontroller platforms besides Arduino?
A: Yes, this board is compatible with a variety of microcontroller platforms that support TTL signaling.
Q: What is the power consumption of this board?
A: The power consumption of this board is typically around 50 mA when active and less than 1 mA when in suspend mode.
