If you own a CO2 Fiber Laser Marking Engraving Machine, then you definitely need the Carved Colored Paper. This amazing product is designed to enhance your laser engraving experience by allowing you to add vibrant colors to your creations. With 12 colors to choose from and a discount rate of 53%, this is a must-have item for any laser engraving enthusiast.
Why You Need It
Direct engraving on materials like glass and ceramics can often be challenging and may not produce the desired results. Laser engraving colored paper is the perfect solution for these issues. The Carved Colored Paper enables you to efficiently engrave patterns on a variety of materials such as ceramics, glass, stone, crystal, and jade. It is compatible with most fiber laser, diode laser, CO2 laser cutters, and engraver machines.
Attention Please
It is important to note that color engraving has high requirements on laser and system parameter settings. The CO2 Laser engraving machine works best for this purpose. Different lasers, materials, and colors of engraving paper require different parameter settings. Therefore, users are advised to adjust the parameters through testing to achieve the best engraving results. If you are not very familiar with these settings, we recommend starting with the black colored paper as it is easier to work with.
Compatibility
The Carved Colored Paper is compatible with almost all laser engravers, including:
- CO2 Laser Engraver Machine
- Fiber Laser Engraver Machine
- UV Laser Marking Machine
- Diode/ Semiconductor Laser
About Colors
It is important to keep in mind that some colors may appear different from their true color after laser engraving. However, we have marked the true color on the back of each paper, so please refer to the marking. There are 12 colors available including black, white, golden, silvery, blue, grey, dusty blue, lake blue, green, army green, brown, and violet.
Size Availability
The Carved Colored Paper comes in four different sizes:
- 36cm*24cm (12 colors)
- 40mm*12mm (black only)
- 35mm*15mm (black only)
- 24mm*24mm (black only)
About Quality
All colored carved papers are carefully packed to ensure their quality. However, due to the long duration of international shipment, some slight creases or lines may be present. Please rest assured that this does not indicate a quality issue and will not affect the engraving process.
How to Use?
Using the Carved Colored Paper is a straightforward process. Here are the steps:
- Distinguish the Front Side – Make sure to place the color side upward when sticking the paper onto an object.
- Cutting Color Paper – Cut the paper to the desired size based on the content of the engraving.
- Soaking Color Paper – Place the cut color paper in water and let it soak for 1-2 minutes. After soaking, peel the colored paper from the backing.
- Stick on the Object – Keep the front side upward and use a scraper to remove any air bubbles or creases. Note that a scraper is necessary for this step. Dry the colored paper with a hairdryer before engraving.
- Prepare to Engrave – Place the object on the engraving machine and select the desired pattern. Pay attention to the direction of the pattern, as you may need to flip it if engraving horizontally.
- Start Engraving – Wait for the engraving process to be completed.
- Soaking the Color Paper – Soak the engraved object in water for 5 minutes after the engraving is complete. Full soaking helps to easily remove excess colored paper.
- Remove Excess Color Paper – Take out the soaked object and patiently remove the excess colored paper. A blade may be needed for this step.
- Product Display – Now, it’s time to let your creativity shine and display your beautifully engraved creation.
Frequently Asked Questions:
Q1: Can the Carved Colored Paper be used on metal surfaces?
A1: No, the Carved Colored Paper cannot be used on any metal surface such as aluminum, stainless steel, or iron.
Q2: What is the size of the Carved Colored Paper?
A2: The Carved Colored Paper is available in different sizes, including 36cm24cm, 40mm12mm, 35mm15mm, and 24mm24mm.
Q3: What laser engraver machines are compatible with the Carved Colored Paper?
A3: The Carved Colored Paper is compatible with most laser engraver machines, including CO2 Laser Engraver Machines, Fiber Laser Engraver Machines, UV Laser Marking Machines, and Diode/Semiconductor Lasers.
