The Ultrasonic Double Sheet Detection Sensor UDC-18GMA-400-3E1 is an indispensable device designed to revolutionize paper handling in your office or business environment. With its advanced ultrasonic technology and exceptional precision, it eliminates paper jams and ensures seamless document processing.
Principle of Operation
The Ultrasonic Double Sheet Detection Sensor utilizes high-frequency sound waves to detect the presence of multiple sheets of paper within its detection zone. When two or more sheets pass through the sensor, the ultrasonic pulses experience interference, causing a disruption in the signal pattern. This disruption is detected by the sensor, which triggers an alarm or activates a pre-programmed action.
Features and Benefits
Exceptional Accuracy: The sensor’s high-frequency ultrasonic technology provides unparalleled accuracy in detecting even the slightest variations in paper thickness, ensuring zuverlässig detection of double sheets.
Versatile Detection Zone: The detection zone can be adjusted to accommodate different paper widths and heights, making it suitable for use with a wide range of paper sizes and documents.
Adjustable Sensitivity: The sensitivity of the sensor can be customized to suit specific application requirements, allowing for optimal performance under varying paper conditions.
Signal Stability: The sensor’s advanced design ensures stable signal transmission even in the presence of environmental factors such as dust or vibrations.
Applications
The Ultrasonic Double Sheet Detection Sensor UDC-18GMA-400-3E1 finds applications in various industries, including:
Office Automation: Eliminates paper jams in printers, copiers, and scanners, improving productivity and reducing downtime.
Document Handling: Ensures accurate sorting and processing of documents by preventing multiple sheets from being fed into machines.
Postal Automation: Detects double envelopes in mail sorting systems, minimizing errors and expediting mail processing.
Specifications
- Sensor Type: Ultrasonic
- Detection Zone: Adjustable (up to 400 mm)
- Sensitivity: Adjustable
- Power Supply: 12-24V DC
- Mounting: Bracket or surface mount
- Dimensions: 23 x 15 x 10 cm
- Weight: 0.5 kg
Frequently Asked Questions
Q: How does the sensor distinguish between single and double sheets?
A: The sensor analyzes the interference pattern of ultrasonic waves passing through the paper. A disruption in the pattern indicates the presence of multiple sheets.
Q: Can the sensor detect different types of paper?
A: Yes, the sensor can detect most types of paper, including copy paper, cardstock, and envelope paper.
Q: Is the sensor maintenance-free?
A: The sensor requires minimal maintenance. Occasional cleaning of the detection zone is recommended to ensure optimal performance.
